Xpelair 93005AW User Manual

Thisapplianceisintendedfor
connectiontoxedwiring.Check
thattheelectricalratingshownon
eachfanmatchesthemainssupply.
THE APPLIANCE IS DOUBLE INSULATED
AND DOES NOT REQUIRE AN EARTH
CONNECTION. Allinstallationsmustbesupervised
byaqualiedelectrician.Installationsandwiring
mustconformtocurrentIEERegulations(UK),local
orappropriateregulations(othercountries).
This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning the use of the
appliance in a safe way and
understand the hazards
involved. Children shall not
play with the appliance.
Cleaning and maintenance
of the appliance shall not be
made by children.
AllXpelairSimplySilent™DX100AC
fanshavethefollowingfeatures:
• Twospeedextraction 
 (Selectableatinstallation)
DX100R/DX100S - Operatethefanusingan
on/oswitch(notsupplied).
DX100TR/DX100TS* - Built-intimeroperatesfan
forapresetdelayfrom30secondsto30minutes.
DX100PR/DX100PS - Operatethefanusingan
integralpull-cord.
DX150HTS/DX150HTR* - Operateswhentriggered
automaticallybytheintegralhumiditysensor,orby
usinganexternalon/oswitch(notsupplied).
In automatic mode: thebuilt-intimerautomatically
operatesthefanforapre-setdelaytimefrom30
secondsto30minutesoncehumiditydropsbelow
thepre-setRelativeHumidity(RH)value.
External operation:Whenswitchedousingthe
externalon/oswitchthefancontinuestorunfor
thepresetdelayfrom30secondsto30minutes.
DX100HPTR/DX100HPTS* - Operateswhen
triggeredautomaticallybytheintegralhumidity
sensor,byusinganexternalon/oswitch(not
supplied),orbyusingtheintegralpullcordswitch.
In automatic mode: Thebuiltintimerautomatically
operatesthefanforthepre-setdelaytimefrom30
secondsto30minutesoncehumiditydropsbelow
thepre-setRelativeHumidity(RH)value.
External operation:Whenswitchedousing
eithertheexternalon/oswitchortheintegral
pullcordswitchthefancontinuestorunforthe
pre-setdelayfrom30secondsto30minutes.
DX100PIRR/DX100PIRS* - Anintegralbody
movementsensoroperatesthefanaslong
asmovementisdetected.Thebuilt-intimer
automaticallyoperatesthefanforapre-setdelayof
upto20minutes.
* Factory settings: Timer 15 minutes, RH 75%
Where to locate the fan.
• Locateitashighaspossible.
• Atleast110mmfromtheedgesof
themountingsurfacetothecentre
ofthehole.
• Asfarawayaspossiblefromandoppositeto
themainsourceofairreplacementtoensure
airowacrosstheroom(e.g.oppositethe
internaldoorway).
• Nearthesourceofsteamorodours.
• Notwhereambienttemperatures
are likely to exceed 50°C.
• Ifinstalledinakitchen
fans must not be mounted
immediately above a cooker
hob, or eye level grill.
• Ifinstallinginaroomcontainingafuelburning
device which has a non-balanced flue, it is the
installer’s responsibility to ensure that there
is enough replacement air to prevent fumes
being drawn down the flue when the fan is
operating up to maximum extract. Refer to
Building Regulations for specific requirements.
• Exhaustairmustnotbedischargedinto
a flue used for exhausting of fumes from
appliances supplied with energy other than
electric. Requirements of all authorities
concerned must be observed for exhaust air
discharge and intake flow rates.
• Notsuitableforuseinpossiblechemical
corrosive atmospheres.
Installation
What the installer will need.
•3mmelectrician’sscrewdriver
 andNo.1or2Pozidrive
 screwdrivers.
English
