Xpelair 93005AW User Manual

Wiring and setting up
G1
SEEDETAILA
DX100R / DX100S
DX11PR/DX100PS
DX100TR / DX100TS
CUSTOMER
CONNECTION
TERMINAL
English
IMPORTANT – PLEASE READ
Adjusting the humidity setting
Adjusting the run on timer setting
Fanswitcheson
atlowerlevelof
condensation
(anti-clockwise)
MORESENTITIVE
(RH=50%)
Fanrunsonfora
shortertimewhen
theexternalswitch
isturnedo
Fandoesnot
switchonuntil
higherlevelof
condensation
(clockwise)
LESSSENTITIVE
(RH=95%)
Fanrunsonfora
longertimewhen
theexternalswitch
isturnedo
Factory settings:
Timer15minutes,RH75%
Maximum30minutesMinimum30seconds
FE
SEEDETAILB
SEEDETAILC
CUSTOMER
CONNECTION
TERMINAL
DETAIL A
SCALE 2.000
HIGH
SPEED
SETJUMPERTOREQUIRED
POSITIONFORSPEEDSETTING
LOW
SPEED
DETAIL C
SCALE 2.000
DETAIL B
SCALE 2.000
SETJUMPERTOREQUIRED
POSITIONFORSPEEDSETTING
HIGH
SPEED
LOW
SPEED
OVER-RUN
TIMER
LEVELLINE
LEVELLINE
