Xprinter XP-470 Series User Manual

Parameter
Default setting
Speed
127 mm/sec (5 ips)
Density
8
Label Width
4” (101.6 mm)
Label Height
7.08” (180 mm)
Media Sensor Type
Gap sensor
Gap Setting
0.157” (4.0 mm)
Print Direction
0
Reference Point
0,0 (upper left corner)
Offset
0
Tear Mode
On
Peel off Mode
Off
Cutter Mode
Off
Serial Port Settings
9600 bps, none parity, 8 data bits, 1 stop bit
Code Page
850
Country Code
001
Clear Flash Memory
No
IP Address
DHCP
4.3 Printer Initialization
Printer initialization is used to clear DRAM and restore printer settings to defaults. The
only one exception is ribbon sensitivity, which will note be restored to default.
Printer initialization is activated by the following procedures.
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns blue after 5 blue blinks. (Any blue will do
during the 5 blinks).

The LED color will be changed as following:
Blue red (5 blinks)  purple (5 blinks) blue (5 blinks) solid blue
Printer configuration will be restore to defaults as below after initialization.
Note：
Always do gap/black mark sensor calibration after printer initialization.
27
