SECTION 4 – REPLACEABLE PARTS
4.1 Ordering Information
The following information must be supplied when ordering a replacement part from your service agent to
ensure that the correct part is supplied:
A. Model or Spec. number of charger (Located on charger data plate)
B. Serial number of charger (Located on charger data plate)
C. Description of part
4.2 Recommended Spares
The quantity of spares stocked should be increased as the number of chargers increases. The following
chart is the minimum quantity recommended per model for multiple charger installations:
# OF CHARGERS
# OF SPARE PARTS KITS
1-3 1
4-10 2
11-25 3
26-50 4
51-100 5
SCHEMATIC REF
DESCRIPTION QUAN. USED QUAN. RECOMMENDED
6 DC FUSE 1 1
2 CONTROL BOARD 1 1
4 HF POWER MODULE 1 TO 4 0
1 POWER SUPPLY 1 0
4.3 Spare Parts List
Part Number Description
Controls
046-0304 Wireless LCD control
Power Supply
049-0539 Power supply, 480VAC
049-0561 Power supply, 120/240VAC (also used on 600V with step-down transformer)
003-2076 Step-down Transformer, 600V to 120V
DC Fuse
011-0243 80A 150VDC Fuse
011-0045 150A 150VDC Fuse
011-0046 200A 150VDC Fuse
011-0047 250A 150VDC Fuse
011-0048 300A 150VDC Fuse
011-0113 350A 150VDC Fuse
011-0049 400A 150VDC Fuse
011-0062 500A 150VDC Fuse
To Next Page
