SECTION 2 - OPERATION
2.1 DESCRIPTION
The 046-0304 charger control provides fully automatic battery charging. The presence of a battery is
detected by the control and causes a charge cycle to begin automatically. The control has charging profiles
that handle standard flooded, gel-cell, and sealed lead-acid batteries, as well as other battery types such as
nickel-cadmium and Li. Each charging profile, or algorithm, uniquely controls the output current and voltage
to optimally charge a particular type of battery, based on battery manufacturer’s recommendations. The
control can be set to start charging at a certain time of day.
Keypad
The keypad has 4 directional buttons, UP(+), DOWN(-), LEFT(=), RIGHT(info), and a center On/Off (I/O)
button.
‐ To terminate a charge cycle, press the I/O button
‐ To select/unselect an equalize cycle for the current charge, press the LEFT(=) button
‐ To view additional charge data during a charge cycle, press the RIGHT(info) button. The data area of
the display will show the data and the units area will display the units for the parameter being displayed.
Press RIGHT(info) again for additional data. After 10 seconds, the display will return to the normal
display of amps.
‐ To view charge history, press the UP(+) or DOWN(-) buttons to display a previous charge cycle. The
charge cycle number will be displayed in the charge cycle message area and the data will be displayed
in the data area along with the units in the units area. Cycle 1 is the most recent and 100 is the oldest.
To view additional data for the charge cycle, press the RIGHT(info) button. The data area of the display
will show the data and the units area will display the units for the parameter being displayed. Press
RIGHT(info) again for additional data. After 10 seconds, the display will return to the normal display of
amps.
LED Indication
The keypad center I/O button has a multi-color LED backlight to indicate charger status.
LED COLOR STATUS
Flashin
GREEN Char
er read
for batter
Solid GREEN Char
e complete
Flashin
AMBER Char
in
Solid AMBER Batter
connected. Char
er OFF
Solid RED
bnormal char
e detected
