Page 123FT-2000D OPERATING MANUAL
MODE-RTY GROUP
078 rtty R PLRTY
Function: Selects normal or reverse Mark/Space polarity
for RTTY receive operation.
Available Values: nor / rEU (REV)
Default Setting: nor
079 rtty T PLRTY
Function: Selects normal or reverse Mark/Space polarity
for RTTY transmit operation.
Available Values: nor / rEU (REV)
Default Setting: nor
080 rtty RTY OUT
Function: Selects the receiver to be connected to the data
output port (pin 2) of the RTTY jack.
Available Values: nAin (Main) / Sub
Default Setting: nAin (Main)
081 rtty OUT LEL
Function: Sets the FSK RTTY data output level at the
output port (pin 2) of the RTTY jack.
Available Values: 0 ~ 100
Default Setting: 50
082 rtty SHIFT
Function: Selects the frequency shift for FSK RTTY op-
eration.
Available Values:170 / 200 / 425 / 850 Hz
Default Setting: 170 Hz
083 rtty TONE
Function: Selects the Mark tone for RTTY operation.
Available Values: 1275 / 2125 Hz
Default Setting: 2125 Hz
MENU MODE
MODE-FM GROUP
074 F3E MICGAIN
Function: Sets the microphone gain for the FM mode.
Available Values: Ur (VR) / 0 ~ 100
Default Setting: 50
When this menu is set to “Ur (VR),” you may adjust the
microphone gain using the front panel’s
[
MIC
]
knob.
075 F3E MIC SEL
Function: Selects the microphone to be used on the FM
mode.
Available Values: Frnt / dAtA / PC
Default Setting: Frnt
Frnt (FRONT): Selects the microphone connected to
the front panel’s MIC jack while us-
ing the FM mode.
dAtA: Selects the microphone connected to
pin 1 of the PACKET Jack while us-
ing the FM mode.
PC: This parameter is for future expansion
of this transceiver’s capabilities, but
at this time is not supported.
076 F3E 28 RPT
Function: Sets the magnitude of the repeater shift on the
28 MHz band.
Available Values: 0 ~ 1000 kHz (10 kHz/step)
Default Setting: 100 kHz
077 F3E 50 RPT
Function: Sets the magnitude of the repeater shift on the
50 MHz band.
Available Values: 0 ~ 4000 kHz (10 kHz/step)
Default Setting: 1000 kHz
