PCB with Components

Printed Circuit Board FR020080C 1-

C 2001 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g2

C 2002 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g2

C 2003 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g2

C 2004 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g1

C 2005 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g2

C 2006 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B g2

C 2007 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B g1

C 2008 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B a2

C 2009 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B a1

C 2010 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e1

C 2011 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e1

C 2012 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e1

C 2013 CHIP CAP. 6pF 50V CH GRM1552C1H6R0DZ01D K22178208 1- B d2

C 2015 CHIP CAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- B d2

C 2016 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D1

C 2017 CHIP CAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- B d2

C 2018 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B g2

C 2019 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B g2

C 2020 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B d2

C 2021 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B d2

C 2022 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B d2

C 2023 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- B f1

C 2024 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1

C 2025 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- B e1

C 2026 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B e1

C 2027 CHIP CAP. 4.7uF 6.3V B JMK107BJ475MA-T K22084803 1- B e1

C 2028 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B e1

C 2029 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 1- B e1

C 2030 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e1

C 2031 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B e1

C 2032 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- B e1

C 2033 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B e1

C 2034 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B e1

C 2035 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2

C 2036 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d2

C 2037 CHIP CAP. 4.7uF 6.3V B JMK107BJ475MA-T K22084803 1- B e1

C 2038 CHIP TA.CAP. 10uF 10V TAJA106M010Y K78100072 1- B c3

C 2039 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e2

C 2040 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B e1

C 2041 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B e2

C 2042 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B e2

C 2043 CHIP TA.CAP. 10uF 10V TAJA106M010Y K78100072 1- B c2

C 2044 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B e2

C 2045 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f1

C 2046 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2

C 2047 AL.ELECTRO.CAP. 10uF 16V UZS1C100MCL1GB K48120030 1- B f2

C 2048 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B e2

C 2049 CHIP TA.CAP. 22uF 6.3V TAJA226M006Y K78080086 1- B b1

C 2050 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B g2

C 2051 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d2

C 2052 AL.ELECTRO.CAP. 47uF 16V UZS1C470MCL1GB K48120031 1- B f2

C 2053 CHIP CAP. 1uF 10V F GRM188F11A105ZA01D K22105001 1- B f1

C 2054 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c1

C 2055 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2

C 2056 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2

C 2057 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f2

C 2058 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- B f2

C 2059 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f2

C 2060 AL.ELECTRO.CAP. 100uF 16V UWX1C101MCL1GB K48120032 1- B f2

C 2061 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B f1

C 2062 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B f1

C 2063 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f1

C 2064 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B h1

D 2001 DIODE DA221 TL G2070178 1- B g1

D 2002 LED SML-512WWT86 G2071104 1- A C1

D 2003 LED SML-512WWT86 G2071104 1- A D1

D 2004 LED SML-512WWT86 G2071104 1- A D1

D 2005 LED SML-512WWT86 G2071104 1- A E1

D 2006 LED SML-512WWT86 G2071104 1- A F1

D 2007 LED SML-512WWT86 G2071104 1- A F1

D 2008 LED SML-512WWT86 G2071104 1- A C2

D 2009 LED SML-512WWT86 G2071104 1- A C2

D 2010 LED SML-512WWT86 G2071104 1- A D2

Parts List

CNTL Unit

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

Brand	Yaesu
Model	FT-2900R
Category	Transceiver
Language	English

Yaesu FT-2900R Technical Supplement
