Yaesu G-450CDC User Manual

2
Controller Front/Rear Panel Controls and Switches
Controller Front Panel
W
S
SE
NE
SW
AZIMUTH INDICATOR
EACH DIVISION 5ｰ
NW
E
270
300
240
330
210
180
0°
90
60
120
30
150
G-450A
OFF
ON
LEFT RIGHT
OVERLAP
CONTROLLER
POWER
190mm
Overlap indicator LED
Indicator needle
adjustment screw
Left-rotation
switch
Right-rotation
switch
Power Switch
125mm
Controller Rear Panel
Adjustment potentiometer selection switch
Indicator needle adjustment potentiometer
Overlap LED adjustment potentiometer
Rotor control interconnection jack
Fuse holder
This holder requires a 1 A (G-450ADC) or 0.5 A
(G-450CDC) fuse. If the fuse is blown, replace
only with a fuse of the same rating.
