SPEC
ELECTRICAL SPECIFICATIONS
ELECTRICAL SPECIFICATIONS
Item Standard Limit
Ignition system
Ignition system type Transistorized coil ignition (digital) ----
Ignition timing 5° BTDC at 1,050 r/min ----
Advancer type Electric ----
Pickup coil resistance/color 420.8 ~ 569.3 Ω/Gy–B ----
Transistorized coil ignition unit model
(manufacturer)
F8T911 (MITSUBISHI) (for Europe)
F8T912 (MITSUBISHI) (for F)
F8T913 (MITSUBISHI) (for Oceania)
----
----
----
Fuses (amperage
×
quantity)
Main fuse 50 A × 1 ----
Fuel injection system fuse 15 A ----
Headlight fuse 25 A × 1 ----
Signaling system fuse 15 A × 1 ----
Ignition fuse 10 A × 1 ----
Radiator fan motor fuse 15 A × 1 ----
Hazard lighting fuse 7.5 A ----
Parking lighting fuse 10 A ----
Backup fuse (odometer and clock) 10 A ----
Windshield motor fuse 2 A ----
Reserve fuse 25 A, 15 A, 10 A × 1
7.5 A × 1 (for Europe)
2.0 A × 1 (for Oceania)
----
----
----

Yamaha 2002 FJR1300 Specifications

General

Bore x Stroke	79.0mm x 66.2mm
Compression Ratio	10.8:1
Fuel System	Fuel injection
Transmission	5-speed
Final Drive	Shaft
Front Suspension	Telescopic fork
Front Brakes	Dual 298mm discs
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Seat Height	805 mm (31.7 in)
Fuel Capacity	25 L (6.6 US gal)
Engine Type	1298cc, liquid-cooled, DOHC, inline 4-cylinder
Ignition	Digital
Rear Suspension	Single shock
Rear Brakes	282mm disc
