EAS00008
SYMBOLS
The following symbols are not relevant to
every vehicle.
Symbols
1
to
9
indicate the subject of each
chapter.
1
General information
2
Specifications
3
Periodic checks and adjustments
4
Chassis
5
Engine
6
Cooling system
7
Fuel injection system
8
Electrical system
9
Troubleshooting
Symbols
0
to
G
indicate the following.
0
Serviceable with engine mounted
A
Filling fluid
B
Lubricant
C
Special tool
D
Tightening torque
E
Wear limit, clearance
F
Engine speed
G
Electrical data
Symbols
H
to
M
in the exploded diagrams
indicate the types of lubricants and lubrication
points.
H
Engine oil
I
Gear oil
J
Molybdenum disulfide oil
K
Wheel bearing grease
L
Lithium soap base grease
M
Molybdenum disulfide grease
Symbols
N
to
O
in the exploded diagrams
indicate the following.
N
Apply locking agent (LOCTITE
®
)
O
Replace the part
12
34
56
78
90
AB
CD
EFG
HIJ
KLM
NO
GEN
INFO
SPEC
CHK
ADJ
CHAS
ENG
COOL
FI
–+
ELEC
TRBL
SHTG
T
R
.
.
E
G
M
B
LS
M
LT
New

Yamaha 2002 FJR1300 Specifications

General

Bore x Stroke	79.0mm x 66.2mm
Compression Ratio	10.8:1
Fuel System	Fuel injection
Transmission	5-speed
Final Drive	Shaft
Front Suspension	Telescopic fork
Front Brakes	Dual 298mm discs
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Seat Height	805 mm (31.7 in)
Fuel Capacity	25 L (6.6 US gal)
Engine Type	1298cc, liquid-cooled, DOHC, inline 4-cylinder
Ignition	Digital
Rear Suspension	Single shock
Rear Brakes	282mm disc
