Yamaha 2004 WaveRunner FX140 User Manual

5-1
E
EJU01116
Troubleshooting
If you have any trouble with your watercraft, use this section to check for the possible
cause.
If you cannot find the cause, or if the procedure for replacement or repair is not described
in this Owner’s/Operator’s Manual, have a Yamaha dealer perform the necessary service.
EJU01367
Troubleshooting chart
TBC-F0P7E
TROUBLE POSSIBLE CAUSE REMEDY PAGE
Engine does not
start
Starter motor does not turn over
Engine shut-
off switch
Clip not in place Install clip
2-8
Fuse Burned out Replace the fuse and
check wiring
4-23
Battery Run down Recharge 4-20
Poor terminal connec-
tions
Tighten as required
4-20
Terminal corroded Clean 4-5
Starter motor Faulty Have serviced by
Yamaha dealer
—
Starter motor turns over
Throttle lever Squeezed Release 2-8
Fuel Empty Refill as soon as possi-
ble
3-4
Stale or contaminated Have serviced by
Yamaha dealer
4-10
Fuel tank Water or dirt present Have serviced by
Yamaha dealer
4-10
Spark plug Fouled or defective Clean or replace 4-15
Spark plug cap Not connected or loose Connect properly 4-15
Connected to wrong
cylinder
Connect properly
4-15
Fuel injection
system
Fuel pump faulty Have serviced by
Yamaha dealer
—
UF1B12.book Page 1 Monday, July 7, 2003 1:48 PM

Yamaha 2004 WaveRunner FX140 Specifications

General

Manufacturer	Yamaha
Model	WaveRunner FX140
Year	2004
Category	Boat
Displacement	1052cc
Width	48.4 inches
Seating Capacity	3 persons
Starter System	Electric
Lubrication System	Wet sump
Cooling System	Water-cooled
Impeller Type	3-blade, stainless steel
Trim System	Manual
Engine Type	4-stroke, 4-cylinder
Fuel Type	Gasoline
Fuel Capacity	18.5 gallons
Bore x Stroke	76 x 58 mm
Fuel System	Electronic Fuel Injection
Hull Type	Modified V
