INSTRUMENT AND CONTROL FUNCTIONS
3-6
3
EAU12347
Handlebar switches
Left
Right (XVS650X)
Right (XVS650AX)
EAU12350
Pass switch “”
Press this switch to flash the headlight.
EAU12400
Dimmer switch “ / ”
Set this switch to “” for the high
beam and to “” for the low beam.
EAU12460
Turn signal switch “ / ”
To signal a right-hand turn, push this
switch to “”. To signal a left-hand
turn, push this switch to “”. When re-
leased, the switch returns to the center
position. To cancel the turn signal
lights, push the switch in after it has re-
turned to the center position.
EAU12500
Horn switch “”
Press this switch to sound the horn.
EAU12660
Engine stop switch “ / ”
Set this switch to “” before starting
the engine. Set this switch to “” to
stop the engine in case of an emergen-
cy, such as when the vehicle overturns
or when the throttle cable is stuck.
EAU12710
Start switch “”
Push this switch to crank the engine
with the starter.
CAUTION:
ECA10050
See page 5-1 for starting instruc-
tions prior to starting the engine.
1. Pass switch “”
2. Dimmer switch “ / ”
3. Horn switch “”
4. Turn signal switch “ / ”
1. Engine stop switch “ / ”
2. Start switch “”
1. Engine stop switch “ / ”
2. Hazard switch “”
3. Start switch “”
