Basic components
13
control. Also, without engine power, the
boat could slow rapidly. This could
cause people and objects in the boat to
be thrown forward.
NOTE:
The engine cannot be started with the lock
plate removed.
EMU26001
Engine stop button
To open the ignition circuit and stop the en-
gine, push this button.
EMU26030
Choke knob
To supply the engine with the rich fuel mixture
required to start, pull out this knob. The choke
knob has the 4 operating positions shown in
the following illustration.
EMU26070
Manual starter handle
To start the engine, first gently pull the handle
out until resistance is felt. From that position,
then pull the handle straight out quickly to
crank the engine.
EMU26122
Steering friction adjuster
A friction device provides adjustable resis-
tance to the steering mechanism, and can be
set according to operator preference. An ad-
justing screw or bolt is located on the swivel
bracket.
1. Lanyard
2. Lock plate
1. Use to start a hot engine
2. Use to warm up a cold engine or restart a
warm engine
3. Use to warm up a cold engine or restart a
warm engine
4. Use to start a cold engine
U63V17E0.book Page 13 Thursday, February 26, 2004 11:52 AM
