Yamaha DTXPLORER Drum Trigger Module DTXPLORER User Manual

30
Specifications
Tone Generator 16 bit AWM2
Maximum polyphony 32
Voices 192 drum, percussion voices
Drum kits 32 Preset
10 User memory locations
Trigger setups 4 Preset
1 User memory location
Sequencer tracks 1
Other Sequencer Functions Mute (rhythm mute), Bass Solo, Groove Check
Song 22 Preset (2 Demo Songs, 20 Pattern Songs)
Controls
Buttons DRUMKIT, CLICK, SONG, >/■, SHIFT, <, >, ON/OFF, SAVE/ENT
Controllers VOLUME, Jog Dial
Display 16 x 2 LCD display (w/Back light)
Connections MIDI OUT
HI HAT CONTROLLER (stereo phone jack)
OUTPUT L/MONO (mono phone jack)
OUTPUT R (mono phone jack)
PHONES (stereo phone jack)
AUX IN (stereo mini jack)
Tr igger Inputs 1, 5, 6 (stereo phone jackmL : trigger input, R : rim switch)
Tr igger Inputs 2, 3, 4, 7 (mono phone jack : trigger input)
Tr igger Input 8/9 (stereo phone jackmL, R : trigger input)
Power supply DC 12V/AC adaptor
Power Requirement 3.2 Watt
Dimensions (W x D x H) 252 x 140 x 54 mm (9-15/16” x 5-1/2” x 2-1/8”)
Weight 835 g (1 lbs. 13 oz.)
Accessories Owner’s Manual
PA-3C AC power adaptor (included or optional depending on local)
* Specifications and descriptions in this owner’s manual are for information purposes only.
Yamaha Corp. reserves the right to change or modify products or specifications at any time without prior notice. Since specifications, equipment or options
may not be the same in every locale, please check with your Yamaha dealer.
