1. Channel Message
Channel messages described below are sent from the drum triggers only.
Other messages are also sent with the sequencer.
1.1 Key On Key Off
Note range: 0 (C-2) to 127 (G8) (10ch only)
Velocity range: 1 to 127 (note on only)
1.2 Control Change
4 - foot controller (10ch only)
1.3 Program Change
2. System Exclusive Message
2.1 Parameter Change
2.1.1 GM system ON
$F0 $7E $7F $09 $01 $F7 (Hexadecimal)
Sets all the data except the MIDI master tuning data to its initial value.
3. System Realtime message
3.1 timing clock
Sends data.
3.2 start, stop
Sends data.
3.3 active sensing
Send the messages within an interval of approximately 300 msec.
MIDI Data Format
Input Instrument Note Number
6 Clash 49
6 Clash edge 57
7 HI-Hat open 46
7 HI-Hat close 42
7 HI-Hat foot close 44
7 HI-Hat foot splash 85
8 Kick 33
9 Option 55
Input Instrument Note Number
1 Snare 31
1 Snare-open rim 34
1 Snare-close rim 37
2 Hi tom 48
3 Mid tom 47
4 Low tom 43
5 Ride 51
5 Ride edge 52
MIDI Transmit Note Number
