5-28
HOUR METER
WIRING THE MECHAN
ICAL HOUR METER
The hour meter counts while th
e ignition switch is “ON”.
WIRING THE DIGI
TAL HOUR METER
Two counting methods can be selecte
d by connecting wires.
Y
Y
B
B
B
L
Batt.+12V
Battery
GND
IG switch
Lamp switch
Hour meter
L
IG switch
Batt.+12V
GND
Battery
Lighting Coil
(alternator)
Hour meter
Positive
Negative
Tach signal
Y
Y
B
B
G
G
IG switch
Batt.+12V
GND
Battery
Hour meter
Positive
Negative
Power signal
Y
Y
B
B
G
COUNTING TIME WHILE ENGINE IS RUNNING
COUNTING TIME WHILE IG SWITCH IS “ON”
