Yamaha F15CWH - Meter Harness

5-32
WIRE HARNESSES
METER HARNESS
For analog meter
For digital meter
Part No. Length (L) Remarks
6Y5-83553-00 2.5 m (8.2 ft)
Part No. Length (L) Remarks
6Y5-83553-10 5 m (16.7 ft)
For pre-mixed
model
B
Y
L
G
LY
G
B
Y
(10A)
YY
( L )
( L )
G
G
Y
G
G/R
G/R
B
Part No. Length (L) Remarks
6Y5-83553-N0 2.5 m (8.2 ft) For twin application
Part No. Length (L) Remarks
6Y5-83553-M0 2.5 m (8.2 ft)
For single applica-
tion
Part No. Length (L) Remarks
6Y5-83553-20 2.5 m (8.2 ft) L/H model
Part No. Length (L) Remarks
6Y5-8356N-00 1.5 m (5 ft) Extension harness
