COOLANT TEMP. METER
ROUTING THE COOLANT TEMP. LEAD
& COOLANT PRESS. TUBE
F150C (VF150A), F165A, F175A, F200 (L4
2.8L)
SENSOR/ATTACHMENT
INSTALLATION AND ROUTING
F200, F225, F250 (V6) [Mechanical RC]
w/ Variable Camshaft Timing
Secure with clamp
Coolant temp.
sensor
Coolant temp. lead
Coolant press. tube
Coolant temp. lead
Coolant press. tube
Coolant temp. lead
Coolant temp. sensorCoolant temp. sensorCoolant temp. sensor
Coolant press. Coolant press.
attachmentattachment
Coolant press.
attachment
