Yamaha F225 User Manual

Engine control system
56

The buzzer will sound intermittently when
the control lever is in the neutral position.
If the alert system has activated, stop the en-
gine immediately and see page 104 of this
manual to drain the water from the fuel filter.
Get back to the port soon and consult a
Yamaha dealer immediately.
NOTICE
ECM02471
Although the buzzer will stop when the
engine is started and the control lever is
moved to the forward or reverse position,
do not use the outboard motor. Other-
wise, serious engine damage could oc-
cur.
ZMU07242
6CE-9-36-1E0.book 56 ページ ２０１４年１１月２８日 金曜日 午後２時５５分
©2019 Yamaha Motor Corporation, U.S.A.

Yamaha F225 Specifications

General

Horsepower	225 hp
Cylinder Arrangement	V6
Full Throttle RPM Range	5000 - 6000 rpm
Alternator Output	50 Amp
Starting System	Electric
Steering	Remote
Fuel Induction System	EFI (Electronic Fuel Injection)
Shaft Length	30"
Engine Type	4-stroke
