MAIN COMPONENTS
1 Top cowling
2 Cowling lock lever
3 Oil drain bolt
* 4 Anode
5 Anti-cavitation plate
6 Trim tab (anode)
7 Propeller
8 Cooling water inlet
9 Trim angle adjusting-rod
0 Clamp bracket
q Tilt support lever
* w Power trim and tilt switch
* e Warning indicator(s)
* r Flushing device
t Remote control box (Side mount type)
* y Tachometer
* u Trim meter
* i Fuel tank
* o Digital tachometer
* May not be exactly as shown; also may not
be included as standard equipment on all
models.
