2-14
GB
EMD58200*
TILT-LOCK MECHANISM
(for hydro-tilt model)
Tilt-lock mechanism is used to prevent
reverse thrust from the propeller lifting
the outboard motor when reversing. To
lock it, set the tilt-lock lever in the Lock
position. To release it, place the tilt-lock
lever in the Tilt position.
1 Tilt-lock lever
NOTE:
The tilt-lock mechanism on the hydro-tilt
model can be used to keep the outboard
motor at a slightly tilted angle for shallow
water cruising. Refer to CRUISING IN
SHALLOW WATER for the correct opera-
tion.
001239
q
EMU01546
FLUSHING DEVICE
This device 1 is used to clean the cooling
water passages of the motor using a gar-
den hose and tap water.
NOTE:
Refer to “CLEANING COOLING-WATER
PASSAGES” in Chapter 4 for instructions
on usage.
62Y-9-7C (E,F,ES) 2 3/22/02 9:06 AM Page 30
