Operation
55
EJU31890
Engine oil
Use a combination of the recommended SAE
and API engine oil classifications shown in the
chart below.
CAUTION:
ECJ00280
Use only 4-stroke engine oil.
EJU31950
Filling the fuel tank
CAUTION:
ECJ00290
Be careful when refueling. Avoid getting
water and other contaminants in the fuel
tank. Contaminated fuel can cause poor
running and engine damage.
(1) Remove the seats. (See page 29 for seat
removal and installation procedures.)
(2) Remove the fuel tank filler cap, and then
slowly add fuel to the fuel tank. Stop filling
when the fuel level reaches approximate-
ly 50 mm (2 in) from the top of the fuel
tank as indicated in the illustration.
(3) Install the fuel tank filler cap and the
seats.
1 Approximately 50 mm (2 in) from top of the
fuel tank
Fuel tank capacity:
70 L (18.5 US gal) (15.4 Imp.gal)
UF1X11E0.book Page 55 Monday, August 7, 2006 3:51 PM
