Maintenance and care
92
● QSTS cables (pulley end)
● QSTS cables (handlebar end)
Remove the QSTS cable housing. Spray a
rust inhibitor into the outer cables. Reinstall
the QSTS cable housing.
● Shift cable (shift lever end)
● Shift cable (reverse gate end)
● Intermediate housing
Fill the intermediate housing with water-re-
sistant grease through the grease nipple
using a grease gun.
EJU34450
Checking the battery
Check the level of the battery electrolyte and
make sure that the negative (–) and positive
(+) battery leads are tightened securely.
Grease quantity:
Initial 10 hours or 1 month:
33.0–35.0 cm³ (1.12–1.18 US oz)
(1.16–1.23 Imp.oz)
Every 100 hours or 12 months:
6.0–8.0 cm³ (0.20–0.27 US oz)
(0.21–0.28 Imp.oz)
1 Grease nipple
UF1X11E0.book Page 92 Monday, August 7, 2006 3:51 PM
