SPECIFICATIONS
TAPE TRANSPORT
Tape Type
Heads
Tape Speed
Pitch Control
Wow & Flutter
Rewind Time
Motor
Chrome (70 microsec. EQ)
4-channel Permalloy rec/play head
4-channel ferrite erase head
4.8 cm/sec 9.5 cm/sec
± 10%
Less than 0.15% WRMS
Approx. 100 sec., for C-60 tape
DC servo motors (2)
CONNECTORS
Input 1 — 4
AUX RETURN L & R
STEREO OUT L & R
PHONES
TAPE OUT 1 — 4
AUX SEND
MONITOR OUT
Input Impedance
Rated Input Level
Max. Input Level
Min. Input Level
Input Impedance
Rated Input Level
Min. Input Level
Output Impedance
Load impedance
Rated Output Level
Load impedance
Max. Output Level
Output Impedance
Load Impedance
Rated Output Level
Output Impedance
Load Impedance
Rated Output Level
Output Impedance
Load Impedance
Rated Output Level
10 k-ohms
-10 dB to -50 dB (fader nominal)
+10 dB (gain control min.)
-56 dB (gain control, fader max.)
10 k-ohms
-10 dB (AUX RETURN level control nominal)
-16 dB (AUX RETURN level control max.)
1 k-ohm
Greater than 10 k-ohms
-10 dB into 50 k-ohms
8 to 40 ohms
45 mW + 45 mW/40 ohms
1 k-ohm
Greater than 10 k-ohms
-10 dB into 50 k-ohms
1 k-ohm
Greater than 10 k-ohms
-10 dB into 50 k-ohms
1 k-ohm
Greater than 10 k-ohms
-10 dB into 50 k-ohms
ELECTRICAL SPECIFICATIONS
Frequency Response
(NR OUT)
50 Hz to 18 kHz, +3 dB/–6 dB at 9.5 cmlsec.
50 Hz to 12.5 kHz, +3 dB/–6 dB at 4.8 cm/sec.
S/N ratio (3% THD Level)
Distortion
Channel Separation
Erasure Ratio
Noise Reduction
Graphic Equalizer
85 dB, dbx ON, IHF-A
1.5% at 315 Hz, dbx on, –10 dB Rec, Level
Greater than 55 dB at 1 kHz, dbx on
Greater than 70 dB at 1 kHz, dbx on
dbx *
100, 400, 1k, 5k, 10kHz (±10 dB), Q = 0.7
GENERAL
Power Requirements
U.S. & Canadian Models: 120 V AC, 60 Hz
(PA100 AC Adaptor)
General Model: 220/240 V AC, 50/60 H
Z
Dimensions (WxHxD)
400 x 76 x 212 mm (15-3/4” x 3” x 8-3/8")
Weight
2.0 kg (4 Ibs 7 oz)
*dbx is
a
trademark
of
dbx Incorporated.
0 dB = 0.775 Vr.m.s.
All specifications subject to change without notice.
23
