 Specifications
* Specifications and appearance are subject to change without notice for improvement.
Product specifications
Dimensions (W x H x D) 480(W) x 44(H) x 351(D)mm, 1U
Weight 4.8 kg
Power supply voltage
Japan: 100V 50/60Hz
US/Canada: 110V–240V 50/60Hz
Others: 100V–240V 50/60Hz
Power consumption 50W (43kcal/h) max.
Heat dissipation (per hour) 43kcal max.
Operating temperature range 0 °C–40 °C
Storage temperature range -20 °C–60 °C
NC value 27
Number of memories Preset memories: 50
Maximum number of simulta-
neously usable devices
Four MTX devices (However in a system in which one to four MTX devices are connected, a total of up
to 20 devices including devices such as the XMV can be connected.)
Power cord length 2.5m
Included items
Power cord, Euroblock plugs (3-pin, tabbed) x 16, Euroblock plug (16-pin) x 1, cable ties x 16,
owner’s manual
Separately sold options DCP1V4S-US/EU digital control panels
Electrical specifications
Sampling frequency 48 kHz
Signal delay Less than 2.5ms (AD-DA @48kHz)
Frequency response 20Hz to 20kHz, -1.5dB min, 0dB typ., +0.5dB max.
Total harmonic distortion Less than 0.05% (+4dBu, Gain:-6dB); less than 0.1% (+4dBu, Gain:+66dB)
Dynamic range 107dB (Gain:-6dB)
Equivalent input noise (EIN) -126dBu (Gain: +66dB)
Crosstalk / Channel separation -100dB (@1kHz)
Maximum cable length
[YDIF] connector: 30 meters (Cable length between devices)
[DCP] connector: 200 meters (total cable length from the MTX3 to the last DCP)
Indicators
INPUT PEAK: RED -3dBFS
INPUT SIGNAL: GREEN -40dBFS
OUTPUT SIGNAL: GREEN -40dBFS
Phantom power 48V (per channel; individually settable)
Connector specifications
Format
[GPI] connector: IN (1-7ch): 0–5V
IN(8ch): 2.5–24V : High, 2.5V or less: Low, Allowable input +24V
OUT: Open collector
+V: DC5V
NETWORK connector: 100Base-TX
[RC-232C] connector: RS-232C (BAUD RATE: 38.4 kbps/115.2kbps)
Cable specifications
[DCP] connector: CAT5e or better Ethernet cable (Straight connected. All 8 pins must be connected.)
[YDIF] connector: CAT5e or better Ethernet STP cable (Straight connected. All 8 pins must be connected.)
NETWORK connector: CAT5e or better Ethernet STP cable
SD Memory card specifications
Supported formats
File formats: FAT32, FAT16, FAT12
Files created on a computer running Windows XP or later, or Mac OS X or later.
Supported capacities
Maximum media capacity: SDHC: Max. 32 GB
SD: Max. 2GB
Maximum file size
(maximum size per file)
FAT12: Max. 32MB
FAT16: Max. 2GB
FAT32: Max. 2GB
Audio file format: WAV
16bit 2ch PCM
Sampling frequencies: 8kHz, 11.025kHz, 12kHz, 16kHz, 22.05kHz, 24kHz, 32kHz, 44.1kHz, 48kHz
Audio file format: MP3
MPEG-1/2/2.5 Audio Layer-3
sampling frequencies: MPEG-1: 32kHz, 44.1kHz, 48kHz
MPEG-2: 16kHz, 22.05kHz, 24kHz
MPEG-2.5: 8kHz, 11.025kHz
Bit rate: MPEG-1: 32kbps–320kbps, VBR (Variable Bit Rate) * However, free format is excepted.
MPEG-2, 2.5: 8 kbps–160 kbps, VBR (Variable Bit Rate) *However, free format is excepted.

Yamaha MTX3 Specifications

General

Sample rate	48 kHz
Frequency range	20 - 20000 Hz
Channels quantity	21 channels
Signal delay (@48kHz)	2.5 ms
Supported sample rates	44.1, 48 kHz
Output impedance	75 Ω
Total Harmonic Distortion (THD)	0.05 %
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	50 W
Product color	Gray
Rack capacity	1U
Rack mounting	Yes
Video capability	No
Nominal input level	-62 dBu
Cables included	AC
Number of Euroblock input connectors	4

Weight and Dimensions

Depth	362 mm
Width	480 mm
Height	44 mm
Weight	4800 g
