Master control section
5
MX12/4—Owner’s Manual
9
ST control
This knob adjusts the monitor level of the external device (tape deck etc.) connected to the
TAPE IN jacks (
5
).
0
DIGITAL EFFECT
MONI control
—This knob adjusts the level of the return signal which is sent from the inter-
nal digital effect to the MONI bus.
ST control
—This knob adjusts the level of the return signal which is sent from the internal
digital effect to the ST bus.
Effect select switches
—These switches select the effect type for the internal digital effect:
VOCAL, L HALL (large hall), or S HALL (small hall).
Do not attempt to turn off all switches or to simultaneously press two or more switches, since
this will cause malfunctions.
ON switch
—This switch turns the internal digital effect on/off. When this is off, no signal will
be sent from the internal digital effect.
A
RTN
MONI control
—This knob adjusts the level of the signal that is sent from the RTN jacks to the
MONI bus.
ST control
—This knob adjusts the level of the signal that is sent from the RTN jacks to the ST
bus. If a signal is input only to the RTN L (MONO) jack, the same signal will be sent to the ST
bus L and R.
B
SEND
MONI 1 control
—This knob adjusts the level of the MONI bus signal that is output to the
SEND MONI 1 jack.
EFFECT/MONI 2 control
—This knob adjusts the level of the EFFECT bus or MONI bus sig-
nal that is output to the SEND EFFECT/MONI 2 jack.
The level of the signal that is sent from the EFFECT bus to the internal digital effect is fixed,
and cannot be adjusted (nor by this control).
Output select switch
—This switch selects the signal that will be output to the SEND EFFECT/
MONI 2 jack.
EFFECT position
()
—The EFFECT bus signal will be output.
MONI 2 position
()
—The MONI bus signal will be output.
C
C-R•PHONES
Here you can select and adjust the signal that is output to the C-R OUT jack and the PHONES
jack.
C-R•PHONES control
— This knob adjusts the output level to the C-R OUT jack and
PHONES jack.
Output select switch
—These switches select the output signal for the C-R OUT jack and
PHONES jack.
•
When the upper switch is on (TAPE IN ), the signal from the TAPE IN
jacks will be output.
•
When the upper switch is off ( )
• When the lower switch is off (ST ), the same signal as the ST OUT-
PUT jacks will be output.
• When the lower switch is on (EFFECT/MONI ), the signal of the
SEND MONI 1 jack will be sent to the L channel, and the SEND
EFFECT/MONI 2 signal will be sent to the R channel.
Meter
—The LEDs indicate the output level before the C-R•PHONES control. A position of 0
indicates nominal level, and when clipping level is approached, PEAK will light red as a warn-
ing.
