Yamaha RX-V320 User Manual

71
RX-V320
Schm
Ref
PARTNO.
Description
✻ New Parts
✻ New Parts
Schm
Ref
PARTNO.
Description
P. C. B. TUNER CHIP RESISTORS
Fi3 VC219000 FLTR.CE SFZ450JL3
IC1 XB760A00 IC LA1266
IC2 XQ944A00 IC LC72131
IC3 iG158100 IC LA3401
L1 Vi546100 COIL 220uH
L2 Vi546100 COIL 220uH
L3 Vi546100 COIL 220uH
L4 Vi546100 COIL 220uH
PK1 V2716700 TUNER.PK ENV‑172A4G1
PK2 VU333700 COIL.RF.AM 940536051A
Q1 iC053540 TR 2SC535A,B,C
Q2 iC053540 TR 2SC535A,B,C
Q3 VD678500 TR.DGT DTA114ES
Q4 iC174020 TR 2SC1740SR,S
Q5 VG722000 TR.DGT DTC144ES
Q6 iC1815I0 TR 2SC1815Y
Q7 VD678500 TR.DGT DTA114ES
R56 HV754470 R.CAR.FP 47 Ω1/4W
ST1 V4040500 SCR.TERM M3
T1 VC218600 COIL.DT.FM 10.7MHz
T2 GE100470 COIL.IF.AM 450KHz
T4 VQ138200 FLTR.LC 19KHz
T5 VQ138200 FLTR.LC 19KHz
TE1 VU477800 TERM.ANT AJ‑2038‑040
TP1 VT969000 PIN.TEST IRS‑2049
TP2 VT969000 PIN.TEST IRS‑2049
VR1 VJ694000 VR.TRIM B47K Ω
VR2 VJ694000 VR.TRIM B47K Ω
XL1 VY734600 RSNR.CRYS 7.2MHz
XL2 GG000750 RSNR.CE 18.95KHz
RD250000 R.CAR.CHP 0 Ω1/10W
RD253100 R.CAR.CHP 1 Ω1/10W
RD254470 R.CAR.CHP 47 Ω1/10W
RD254510 R.CAR.CHP 51 Ω1/10W
RD255100 R.CAR.CHP 100 Ω1/10W
RD255220 R.CAR.CHP 220 Ω1/10W
RD255330 R.CAR.CHP 330 Ω1/10W
RD255470 R.CAR.CHP 470 Ω1/10W
RD255910 R.CAR.CHP 910 Ω1/10W
RD256100 R.CAR.CHP 1K Ω1/10W
RD256110 R.CAR.CHP 1.1K Ω1/10W
RD256220 R.CAR.CHP 2.2K Ω1/10W
RD256270 R.CAR.CHP 2.7K Ω1/10W
RD256330 R.CAR.CHP 3.3K Ω1/10W
RD256390 R.CAR.CHP 3.9K Ω1/10W
RD256470 R.CAR.CHP 4.7K Ω1/10W
RD256510 R.CAR.CHP 5.1K Ω1/10W
RD256620 R.CAR.CHP 6.2K Ω1/10W
RD256820 R.CAR.CHP 8.2K Ω1/10W
RD257100 R.CAR.CHP 10K Ω1/10W
RD257110 R.CAR.CHP 11K Ω1/10W
RD257270 R.CAR.CHP 27K Ω1/10W
RD257470 R.CAR.CHP 47K Ω1/10W
RD257680 R.CAR.CHP 68K Ω1/10W
RD257910 R.CAR.CHP 91K Ω1/10W
RD258100 R.CAR.CHP 100K Ω1/10W
RD258200 R.CAR.CHP 200 Ω1/10W
RD259100 R.CAR.CHP 1M Ω1/10W
