63
RX-V350/HTR-5730
RX-V350/HTR-5730
Schm
Ref. PARTNO. Description Remarks Markets
P.C.B. FUNCTION & P.C.B. MAIN
✻ New Parts
SW573 VV020300 SW.TACT SKQNAA BGE
SW671 VV020300 SW.TACT SKQNAA
SW691 VZ075500 SW.SLIDE SL14‑22AM5F RL
* U551 WC746300 L.DTCT RPM7138‑H9
* V551 WC173100 FL.DSPLY 16‑BT‑122GNK
WA790800 SHEET
WA790900 SPACER 4.6/10/32
* WC762300 P.C.B. MAIN UC
* WC762400 P.C.B. MAIN R
* WC762500 P.C.B. MAIN T
* WC762600 P.C.B. MAIN K
* WC762700 P.C.B. MAIN A
* WC762800 P.C.B. MAIN BGE
* WD043700 P.C.B. MAIN L
CB101 VQ963000 CN.BS.PIN 9P
CB102 VQ584800 CN.BS.PIN 6P
CB103 VK024700 CN.BS.PIN 3P
CB104 LB932040 CN.BS.PIN 4P
CB105 Vi878200 CN.BS.PIN 4P
CB242 VM859600 CN.BS.PIN 15P
CB244 VQ963300 CN.BS.PIN 12P
CB245 Vi878300 CN.BS.PIN 5P
CB246 VF728200 CN.BS.PIN 10P
CB247 VQ963000 CN.BS.PIN 9P
CB248 VQ044400 CN.BS.PIN 9P
CB249 VQ963500 CN.BS.PIN 14P
CB371 Vi878100 CN.BS.PIN 3P
CB372 VP206500 HOLDER.FUS EYF‑52BCT
CB373 VP206500 HOLDER.FUS EYF‑52BCT
CB374 VG879900 CN.BS.PIN 2P
CB375 VG879900 CN.BS.PIN 2P
CB391 VK026400 CN.BS.PIN 5P
CB411 VQ584800 CN.BS.PIN 6P
C101 UA654100 C.MYLAR 0.01uF50V
C102 UR877100 C.EL 10uF63V
C103 UR877100 C.EL 10uF63V
C104 UR877100 C.EL 10uF63V
C105 UR877100 C.EL 10uF63V
C106 UR877100 C.EL 10uF63V
C107 UA652220 C.MYLAR 220pF50V
C108 UA652220 C.MYLAR 220pF50V
C109 UA652220 C.MYLAR 220pF50V
C110 UA652220 C.MYLAR 220pF50V
C111 UA652220 C.MYLAR 220pF50V
C112 UR877100 C.EL 10uF63V
C113 UR877100 C.EL 10uF63V
C114 UR867330 C.EL 33uF50V
C115 UA652100 C.MYLAR 100pF50V
C116 UR877100 C.EL 10uF63V
C117 UR877220 C.EL 22uF63V
To Next Page
