Yamaha RX-V350 Service Manual

65
RX-V350/HTR-5730
RX-V350/HTR-5730
Schm
Ref. PARTNO. Description Remarks Markets
P.C.B. MAIN
✻ New Parts
C254 UR877100 C.EL 10uF63V
C256 UR847470 C.EL 47uF25V
C258 WB165500 C.EL 0.33F5.5V
C259 UR818220 C.EL 220uF6.3V
C260 UR847470 C.EL 47uF25V
C261 UR837330 C.EL 33uF16V
C263 UR877100 C.EL 10uF63V
C264 UR818470 C.EL 470uF6.3V
C274 UR847470 C.EL 47uF25V BGE
C275 UR847470 C.EL 47uF25V BGE
C277 VA761100 C.CE 27pF50V BGE
C279 VA761100 C.CE 27pF50V BGE
C280 UR847470 C.EL 47uF25V BGE
C283 UR866220 C.EL 2.2uF50V
C284 UR866220 C.EL 2.2uF50V
C285 UR866220 C.EL 2.2uF50V
C286 UR866220 C.EL 2.2uF50V
C371 UR858470 C.EL 470uF35V
C372 UA654100 C.MYLAR 0.01uF50V
C373 UR867100 C.EL 10uF100V RL
C374 UA654100 C.MYLAR 0.01uF50V UCTKABGE
C375 UA654100 C.MYLAR 0.01uF50V RL
C376 UA654100 C.MYLAR 0.01uF50V RL
s C377 WB121400 C.CE.SAFTY 0.01uF295V
C393 UR877100 C.EL 10uF63V
C394 UR877100 C.EL 10uF63V
C395 UR877100 C.EL 10uF63V
C396 UR877100 C.EL 10uF63V
C397 UR829100 C.EL 1000uF10V
C398 UR829100 C.EL 1000uF10V
C401 UR838100 C.EL 100uF16V
C411 UA654100 C.MYLAR 0.01uF50V RTKABGEL
C412 UA654100 C.MYLAR 0.01uF50V RTKABGEL
C415 UA654100 C.MYLAR 0.01uF50V
C415 UA654100 C.MYLAR 0.01uF50V KABGEL
C416 UA654100 C.MYLAR 0.01uF50V KABGEL
C417 UA652100 C.POL 100pF50V KABGEL
D101 VT332900 DIODE 1SS355
D102 VT332900 DIODE 1SS355
s D103 VD631600 DIODE 1SS133,176
D104 VD631600 DIODE 1SS133,176
D105 VD631600 DIODE 1SS133,176
D106 VG441600 DIODE.ZENR MTZJ20A 20V
D106 VG441600 DIODE.ZENR MTZJ20A 20V RTKABGEL
D106 VG441700 DIODE.ZENR MTZJ20B20V UC
* D107 WC398800 DIODE KDS160‑RTK
D108 VN008700 DIODE 1SS270A
D109 VN008700 DIODE 1SS270A
* D110 WC398800 DIODE KDS160‑RTK
D111 VN008700 DIODE 1SS270A
D112 VN008700 DIODE 1SS270A
D113 VN008700 DIODE 1SS270A
D114 VN008700 DIODE 1SS270A

Yamaha RX-V350 Specifications

General

Channels	5.1
Dolby Digital	Yes
DTS	Yes
FM/AM Tuner	Yes
Impedance	6 ohms
Type	AV Receiver
Input Sensitivity	200 mV
Signal-To-Noise Ratio	100 dB
Total Harmonic Distortion	0.06%
Frequency Response	10Hz - 100kHz
Amplifier Type	Discrete
Power Output	100W per channel
Outputs	1 x Audio, 1 x Video
Surround Sound Formats	Dolby Digital, Dolby Pro Logic II, DTS
Input Impedance	47 kOhms
Audio Inputs/Outputs	RCA
Digital Audio Inputs	2 (1 x Optical, 1 x Coaxial)
Video Inputs/Outputs	Composite
