Yamaha RX-V350 Service Manual

68
RX-V350/HTR-5730
RX-V350/HTR-5730
Schm
Ref. PARTNO. Description Remarks Markets
P.C.B. MAIN
✻ New Parts
R132 HV753220 R.CAR.FP 2.2Ω1/4W
s R133 HV754100 R.CAR.FP 10Ω1/4W
s R143 HV756470 R.CAR.FP 4.7KΩ1/4W
s R144 HV754100 R.CAR.FP 10Ω1/4W
R148 WB279900 R.WW RGC55C0.22+0.22
R156 WB279900 R.WW RGC55C0.22+0.22
R157 WB279900 R.WW RGC55C0.22+0.22
R158 WB279900 R.WW RGC55C0.22+0.22
R159 WB279900 R.WW RGC55C0.22+0.22
R166 HV753470 R.CAR.FP 4.7Ω1/4W
s R171 VP939700 R.MTL.FLM 4.7Ω1W
R178 HV753470 R.CAR.FP 4.7Ω1/4W
R180 HV753470 R.CAR.FP 4.7Ω1/4W
R182 HV753470 R.CAR.FP 4.7Ω1/4W
R184 HV753470 R.CAR.FP 4.7Ω1/4W
R190 VP939700 R.MTL.FLM 4.7Ω1W
s R191 VP939700 R.MTL.FLM 4.7Ω1W
s R192 VP939700 R.MTL.FLM 4.7Ω1W
s R193 VP939700 R.MTL.FLM 4.7Ω1W
R198 HV756470 R.CAR.FP 4.7KΩ1/4W
R201 HV755330 R.CAR.FP 330Ω1/4W
R204 HV753220 R.CAR.FP 2.2Ω1/4W RTKABGEL
R206 HV753220 R.CAR.FP 2.2Ω1/4W RTKABGEL
R208 HV753220 R.CAR.FP 2.2Ω1/4W
R216 HV753220 R.CAR.FP 2.2Ω1/4W RTKABGEL
R217 HV753220 R.CAR.FP 2.2Ω1/4W RTKABGEL
R243 HV753220 R.CAR.FP 2.2Ω1/4W
R378 VC757900 R.MTL.OXD 47Ω2W RL
R380 V6730000 R.CAR. 2.2MΩ1/2W UC
R399 HV755270 R.CAR.FP 270Ω1/4W
R405 HV753220 R.CAR.FP 2.2Ω1/4W
R411 HV753220 R.CAR.FP 2.2Ω1/4W RTKABGEL
R414 HV753220 R.CAR.FP 2.2Ω1/4W RTKABGEL
RY101 V5966300 RELAY DS24D2‑OS(M)
RY102 V5966300 RELAY DS24D2‑OS(M)
RY104 V5178900 RELAY DCDQ24D1‑OS(M)
RY105 V5966300 RELAY DS24D2‑OS(M)
s RY371 V2712300 RELAY DCSDT‑S‑112LMR
RY411 V5966300 RELAY DS24D2‑OS(M)
ST241 WA789600 SCR.TERM M3
ST371 WA789600 SCR.TERM M3
SW391 V3624300 SW.SLIDE SS029‑P022MJB‑PA6 RL
s T371 XW606A00 TRANS.PWR UC
s T371 XW974A00 TRANS.PWR RL
s T371 XW608A00 TRANS.PWR T
s T371 XW608A00 TRANS.PWR KABGE
TE101 VY696300 TERM.SP 4P UCRTA
TE101 VY696400 TERM.SP 4P KBGEL
TE102 WB054000 TERM.SP YKD21‑5002N
TE411 WB054100 TERM.SP YKD21‑5004N
XL241 V3930900 RSNR.CRYS 4.332MHz BGE
XL242 WB213000 RSNR.CE 16.0MHz
EP600140 SCR.BND.HD 3x10MFZN2BL

Yamaha RX-V350 Specifications

General

Channels	5.1
Dolby Digital	Yes
DTS	Yes
FM/AM Tuner	Yes
Impedance	6 ohms
Type	AV Receiver
Input Sensitivity	200 mV
Signal-To-Noise Ratio	100 dB
Total Harmonic Distortion	0.06%
Frequency Response	10Hz - 100kHz
Amplifier Type	Discrete
Power Output	100W per channel
Outputs	1 x Audio, 1 x Video
Surround Sound Formats	Dolby Digital, Dolby Pro Logic II, DTS
Input Impedance	47 kOhms
Audio Inputs/Outputs	RCA
Digital Audio Inputs	2 (1 x Optical, 1 x Coaxial)
Video Inputs/Outputs	Composite
