Specifications
INTERFACE SPECIFICATIONS
*1 SWP1-8MMF, SWP1-8
*2 SWP1-16MMF
*3 These terminals support AutoMDI/MDI-X
*4 The SWP1-8MMF supports the option for port 10, and the SWP1-8 supports the option for both ports 9 and 10
*5 The SWP1-16MMF supports the option for port 18
*6 For the pin assignments, refer to CONNECTOR PIN ASSIGNMENTS
*7 Pin 4=+24VDC, pin 1=GND, pins 2 and 3=N.C.
External power supply requirements: 24VDC±2V, 1A
*8 Conforming cable: GI-type multi-mode fiber cables with a core diameter /cladding diameter of approximately 50 μm/125 μm.
Maximum cable length: 300 m
ELECTRICAL CHARACTERISTICS
Terminal Format Level Connector
1-8
*1
1-8,13-16
*2 *3
IEEE802.3 10BASE-T/100BASE-TX/
1000BASE-T
etherCON CAT5e
9-12
*2 *3
IEEE802.3 10BASE-T/100BASE-TX/
1000BASE-T
RJ-45
9,10
*4
17,18
*5 *8
IEEE802.3 1000BASE-SX opticalCON
CONSOLE (RS-232C) – RS-232C RJ-45
*6
EXT DC INPUT – – XLR-4-32 type
*7
PARAMETER CONDITIONS MIN TYP MAX UNITS
Power
Requirements
SWP1-8 J,U/C,E 100-240V 50/60Hz 11 W
0.21 A
SWP1-8MMF J,U/C,E 100-240V 50/60Hz 11 W
0.21 A
SWP1-16MMF J,U/C,E 100-240V 50/60Hz 16 W
0.29 A
Heat Dissipation SWP1-8 J,U/C,E 100-240V 50/60Hz 9.5 kcal/h
SWP1-8MMF J,U/C,E 100-240V 50/60Hz 9.5 kcal/h
SWP1-16MMF J,U/C,E 100-240V 50/60Hz 14 kcal/h
Temperature range Operating temperature range 0 40 °C
Storage temperature range -20 60 °C
AC cord Length 2450 2500 2550 mm
