2-1
1
2
3
4
5
6
7
8
9
DESCRIPTION
EAU10410
Left view
1
2
3 4 5 6
7789101112
1
2
3456
1. Front fork spring preload adjusting bolt (page 3-15)
2. Front fork damping adjusting screw (page 3-15)
3. Air filter element (page 6-12)
4. Coolant reservoir (page 6-10)
5. Battery (page 6-27)
6. Fuses (page 6-28)
7. Luggage strap holder (page 3-18)
8. Seat lock (page 3-14)
9. Shock absorber assembly rebound damping force adjusting knob
(page 3-17)
10. Shock absorber assembly spring preload adjusting ring (page 3-17)
11. Shift pedal (page 3-10)
12. Engine oil drain bolt A (page 6-7)
