General| Displacement | 660cc |
|---|---|
| Bore x Stroke | 100.0 mm x 84.0 mm |
| Compression Ratio | 10.0:1 |
| Fuel System | Electronic Fuel Injection |
| Ignition System | TCI |
| Starter System | Electric |
| Transmission | 5-speed |
| Final Drive | Chain |
| Rear Suspension | Swingarm |
| Front Tire | 90/90-21 |
| Rear Tire | 130/80-17 |
| Length | 2, 240 mm |
| Width | 865 mm |
| Height | 1, 230 mm |
| Seat Height | 865 mm |
| Wet Weight | 181 kg |
| Fuel Capacity | 15 liters |
| Lubrication System | Dry sump |
| Engine Type | Liquid-cooled, 4-stroke, SOHC, 4-valve |
| Front Suspension | Telescopic fork |
| Front Brake | Single disc, 298 mm |
| Rear Brake | Single disc, 245 mm |
| Maximum Power | 35 kW (48 PS) @ 6, 000 rpm |
| Maximum Torque | 58 Nm @ 5, 250 rpm |
