3-12
ENGINE
The thickness "a" of each pad is indi-
cated in hundredths of millimeters on
the pad upper surface.
d. Round off the last digit of the in-
stalled pad number to the nearest
increment.
EXAMPLE:
Installed pad number = 148
Rounded off value = 150
Pads can only be selected in 0.05
mm increments.
e. Locate the rounded-off value and
the measured valve clearance in
the chart "PAD SELECTION TA-
BLE". The field where these two
coordinates intersect shows the
new pad number to use.
Use the new pad number only as a
guide when verifying the valve clear-
ance adjustment.
f. Install the new pads "3" and the
valve lifters "4".
•Apply the engine oil on the valve lift-
ers.
•Apply the molybdenum disulfide oil
on the valve stem ends.
•Valve lifter must turn smoothly
when rotated with a finger.
•Be careful to reinstall valve lifters
and pads in their original place.
g. Install the camshafts (exhaust
and intake).
Refer to "CAMSHAFTS" section
in the CHAPTER 4.
Last digit of pad
number
Rounded valve
0, 1 or 2 0
4, 5 or 6 5
8 or 9 10
To Next Page
