68 OPE_EF312T&352T_en.doc
SPECIFICATIONS
Model
EF312T（4WD） EF352T（4WD）
Make Yanmar
Model 3TNV84 3TNV88
Type Direct injection, Water cooled, diesel
SAE Gross (hp) 30.1 34.5
Output
SAE Gross (ps) 30.5 35.0
Rated RPM (rpm) 2500 2600
No. of cylinders 3
Displacement (cc) 1,496 cc 1,642 cc
Engine
Fuel tank (lit.) 28
Overall length (mm) 2850
Overall width (mm) 1325
Overall height (steering wheel) (mm) 1365
Front (mm) 1000
Tread
Rear (mm) 1025, 1105
Wheelbase (mm) 1600
Dimension
Ground clearance (mm) 350
Weight (kg) 920 920
Front 7 - 14 7 - 14
Tire size
Rear 11.2 - 24 11.2 - 24
Steering Hydrostatic power steering
Brake Wet multi-disc type
Clutch Dry single
No. of shifting gears
8 forward and 8 reverse
(constant & sliding mesh)
Reverser Synchro-mesh
Forward (km/hr) 1.29 – 22.5 1.34 – 23.4
Transmission
Travel speed
Reverse (km/hr) 1.26 - 22.1 1.31 – 23.0
Turning radius (m) 2.2
Gear 1 540 rpm 560 rpm
PTO
Gear 2 785 rpm 815 rpm
Type Position control
Hitch 3-point hitch
Category Category 1
Max. lifting capacity (at lower link end) (kg) 1000
Hydraulic
system
Hydraulic pump capacity (lit./min) 22 23
Note:
All technical data, measurement and weight are approximate, and the manufacturer has the right to make
alteration without prior notice.
