Yard force COMPACT 280R User Manual

12 13
GB GB
Press STOP button to halt the mower at any time.
Return to Docking station
Cutting height adjustment
The cutting height can be adjusted by rotating the height adjustment dial located on the top of
the machine. Cutting height range from 20mm - 55mm.
NOTE!
We recommend using an ordinary lawn mower or trimmer to cut the lawn below 45mm before
using the Robotic Mower. This will ensure you get the optimum performance.
Emergency Stop
Technical Data
Model 280R 400Ri
APP control
Max cutting area 280 m
2
400 m
2
Battery pack 20V/2000mAh 20V/2000mAh
Switch power supply
Input: 100-240V AC, 50/60Hz,
42W
Output:24VDC, CC1.5A
Input: 100-240V AC, 50/60Hz,
42W
Output:24VDC, CC1.5A
Mowing time on one charge 60 min 60 min
Rated voltage 20 V 20 V
Rated power 42 W 42 W
No load speed 3500/min 3500/min
Cutting width 16 cm 16 cm
Cutting height Approx 20-55 mm Approx 20-55 mm
Charging time 100 min 100 min
Weight 7.4 Kg 7.4 Kg
Frequency Band 0-148.5KHz 0-148.5KHz
Magnetic Field Strength 60dBμA/m 60dBμA/m
Wireless Standards IEEE 802.11 n/g/b
Wireless Frequency Rang/Power 2.4-2.4835GHz/<20dBm
Degree of protection:
Robotic Mower IP24 IP24
Switching power supply IP67, Plug IP44 IP67, Plug IP44
Spare parts
Spare Blades 3 Pcs 3 Pcs
Boundary pegs 100 Pcs 120 Pcs
Boundary wire 80 m 100 m
Connectors 3 Pcs 3 Pcs
1 2

Yard force COMPACT 280R Specifications

General

Type	Robotic lawn mower
Motor type	Brushless
Cutting width	160 mm
Product color	Black, Orange
Maximum lawn area	280 m²
Maximum cutting height	55 mm
Minimum cutting height	20 mm
Suitable for slope up to	30 %
Number of height positions	3
Cutting clearance adjustment	Yes
Battery type	Built-in battery
Power source	Battery
Battery voltage	20 V
Battery capacity	2 Ah
Battery life (max)	60 min

Weight and Dimensions

Depth	384 mm
Width	440 mm
Height	206 mm
Weight	7400 g
Package depth	415 mm
Package width	650 mm
Package height	270 mm
Package weight	15000 g
