PARTS LIST
25
YD4103PM02 - 1706
|
Parts List
No. Description
Qty
1 Engine 1
2 Handle Sleeve 2
3 ON/OFF Switch 1
4 Throttle Lever 1
5 Throttle Cable 1
6 Locknut M6 17
7 Clutch Control Lever 1
8 Screw M6X55 1
9 Clutch Control Cable 1
10 Hoop 2
11 Steering Lever 2
12 Right/Left Steering Cable 2
13 Hopper 1
14 Screw M6x55 1
15 Washer 6 32
16 Lock nut M10 56
17 Washer 10 51
18 Cable Plate 1
19 Rocker Lever 1
20 Dumper Box Cable 1
21 Mounting Base for Engine 1
22 Square Neck Bolt 4
23 Pulley Front Cover 1
24 Pulley Back Cover 1
25 Bolt M8X16 1
26 Spring Washer 8 9
27 Lock Nut M8 46
28 Washer 8 48
29 Bolt M8X20 18
30 Flange Nut M8 10
31 Bolt M8X40 4
32 Bolt M8X60 1
33 Gear Box 1
34 Screw M6X35 1
35 Flange Nut M10 9
36 Plain washers-Large 6
No. Description
Qty
37 Belt Pulley 1
38 Flat Key B5x40 1
39 Belt Shaft 1
40 Circlip 8 1
41 Rockshaft 1
42 Cable Fixed Pin 1 4
43 Thin Nut M10 4
44 Taper Knob 1
45 Bolt M8X25 5
46 Fixed Bracket 1
47 Bolt M10X45 4
48 Bolt M10X25 12
49 Handle Frame Assembly 1
50 Cover Weldment 2
51 Bolt M6X16 21
52 Spring Washer 6 24
53 Pin
4 2
54 Chain Guide Posts 2
55 Bolt M8X70 2
56 Rubber Bolt M8X25 2
57 Chain 2 2
58 Chain 1 2
59 Pull Plate 1
60 B-Belt 1
61 Belt Guide Weldment 1
62 Screw M6X16 1
63 Oil Nipple M6 1
64 Tensioner Pulley Bracket 1
65 Circlip 15 1
66 Circlip 35 1
67 Bearing 6202 2
68 Tensioner Pulley 1
69 Bolt M6X25 1
70 Bolt M12X65 1
71 Flange Nut M12 17
72 Limiting Plate 1
No. Description
Qty
73 Chasis 1
74 Fender 4
75 Rear Chainwheel 2
76 Bearing 205 4
77 Bush 2 2
78 Flat Key C8X60 2
79 Rear Rim 2
80 Flat Key A10X60 2
81 Left Wheel 2
82 Front Rim 2
83 Bush 1 4
84 Bearing 305 4
85 Front Rim 2
86 Washer 40x13.5x4 4
87 Spring Washer 12 20
88 Bolt M12X20 4
89 Small Connecting Plate 2
90 Wheel Axle Press Board 2
91 Spring 2
92 Bolt M8X50 1
93 Bolt M8X175 6
94 Bolt M10X25 13
95-1
Lock nut M12 16
96 Washer 12 16
97
Bolt M10X70
1
98 Screw M6X20 6
99 Chain Pad (Right) 1
100 Chain Pad (Left) 1
101 Lever Knod 1
102 Lever 1
103
Pin 3X30
1
104 Pin 5x30 1
105 Orientation Nut 1
106 O-Ring 17x1.8 1
107 O-Ring 11.2x1.8 1
108 Lever Mount Bracket 1
To Next Page
