YARDMAX YM0046 User Manual

Your YARDMAX concrete mixer comes partially assembled and contains the following:
1. Upper Drum
2. Bottom Drum with Support Arm
3. Locking Plate
4. Motor Assembly
5. Tipping Bar
6. Mixing Blades (1 Pair)
7. Support Leg
8. Support Frame
9. Wheel Axle Bracket
10. Wheels (1 Pair)
11. Motor Support Bracket
12. Operator’s Manual
13. Hardware Bag
CONTENTS SUPPLIED
× 2
1
M8 × 40 × 1
2
M8 × 60 × 1
TOUCH-UP PAINT
Orange X 1
10
Light Gray X 1
M8 × 40 × 1
3
M8 × 60 × 1
M8 × 55 × 2
4
M8 × 20 × 2
5
M6 × 16 × 6
6
M8 × 16 × 2
M8 × 25 × 2
7
M8 × 55 × 1
8
× 1
M8 × 60 × 1
9
M8 × 2
HARDWARE KIT
21
54
3
6 7 8 9
13121110
6
Electric Concrete Mixer
»
Operator’s Manual
Contents Supplied
|
74005US25M100.indd 6 2017/3/14 11:12:17

YARDMAX YM0046 Specifications

General

Brand	YARDMAX
Model	YM0046
Category	Mixer
Language	English
