No. Description QTY.
1 Cross Headed Screw M8×20 10
2 Waterproof Washer 4
3 Flat Washer 8 22
4 Spring Washer 8 18
5 Nut M8 18
6 Upper Drum 1
7 Mixing Blade 2
8 Rubber Gasket 1
9 Bottom Drum 1
10 Wheel Axle Bracket 1
11 Wheel 2
12 Flat Washer 27 4
13 cotter pin 5×40 4
14 Support Frame 1
15 Support Leg 1
16 Bolt M8×70 4
17 Motor Support Bracket 1
18 Circlip 42 1
19 O-ring 1
20 Gear Guard - Long 1
21 Drive Shaft 1
22 sleeve pipe 2
23 Cradle 1
24 Bearing 6206 2
25 Circlip 62 3
26 Circlip 30 1
27 Elastic pin 5×40 1
28 Self Tapping Screw ST4.2×13 3
29 Drive pinion 1
30 Gear Guard - Short 1
31 Circlip 42 1
32 Bearing 6202 2
33 Circlip 15 1
34 Lock Nut M8 4
35 Bolt M8×65 2
No. Description QTY.
36 Circlip 38 2
37 Support Seat 1
38 Lock Nut M10 1
39 Flat Washer 10 2
40 Spring 1
41 Hex.head bolt M10×65 1
42 Tipping Bar 1
43 Handle Grip 1
44 Bolt M8×25 5
45 Locking Plate 1
46 Electric Cord 1
47 Strain Relief Nut 1
48 Strain Relief Rubber 1
49 Strain Relief Bolt 1
50
Strain Relief Nut
1
51 Switch Gasket 1
52 Switch 1
53 Motor Cover 1
54 Motor 1
55 Idle Pulley 1
56 Belt 1
57 Bearing 6906 2
58 Snap Washer – Hole 47 1
59 Self Tapping Screw ST4.2×16 6
60 Circlip 30 1
61 End Plate 1
62 Bolt M8×25 3
63 Motor Mount Bracket, End Plate 1
64 Gasket 1
65 Self Tapping Screw ST3.5×16 2
66 Oil seal 62×35×8 1
67 Fixed Shaft 1
68 Washer 1
69 Spring Washer 12 1
70 Bolt M12×35 1
PARTS LIST
17
|
Parts List
