YARDMAX YM0115 User Manual

Your YARDMAX concrete mixer comes partially assembled and contains the following:
1. Upper Drum
2. Bottom Drum with Support Arm
3. Locking Plate
4. Motor Assembly
5. Tipping Bar
6. Mixing Blades (1 Pair)
7. Support Leg
8. Support Frame
9. Wheel Axle Bracket
10. Wheels (1 Pair)
11. Motor Support Bracket
12. Operator’s Manual
13. Hardware Bag
CONTENTS SUPPLIED
HARDWARE KIT
6 7 8
21
9
13121110
54
3
× 4
1
M8 × 70 × 2
2
M8 × 70 × 2
3
TOUCH-UP PAINT
Orange X 1
10
Light Gray X 1
M8 × 65 × 2
4
Ø 42 × 1
M8 × 20 × 2
5
M8 × 20 × 6
6
M8 × 20 × 2
M8 × 25 × 2
7
M10 × 65 × 1
8
× 1
M8 × 4
9
6
Electric Concrete Mixer
»
Operator’s Manual
Contents Supplied
|
74013US25M101.indd 6 2017/3/14 11:28:42
