10
KNOW YOUR STRING TIMMER (See Fig. 1)
The safe use of this product requires an understanding of the information on the tool and in this
product, familiarize yourself with all operating features and safety rules.
CORD RETAINER
A convenient cord retainer helps keep the extension cord connection secure during string trimmer
operation.
EDGER GUIDE
The easily mounted edger guide allows the string trimmer to perform as an edger.
FRONT HANDLE
The string trimmer is equipped with a front handle assembly for ease of operation and to prevent
loss of control.
GRASS DEFLECTOR
ROTATING REAR HANDLE
The rotating rear handle on the string trimmer can be locked in two different positions for ease of
use when edging.
TELESCOPING BOOM
FEATURES
TELESCOPING
BOOM COUPLER
EDGING COUPLER
GRASS
DEFLECTOR
ROTATING
REAR
HANDLE
SWITCH
TRIGGER
CORD
RETAINER
ADJUSTABLE
FRONT HANDLE
Fig. 1
EDGE GUIDE
TELESCOPING
SHAFT
