Yealink SIP-T19P Quick Start Guide

E
N
G
L
I
S
H
3
Conguring Your Phone
Conguring via web user interface
Accessing the web user interface:
1. Press when the phone is idle to obtain the IP address of the phone.
2. Open the web browser on your computer, enter the IP address into the address bar (e.g.,
“http://192.168.0.10” or “192.168.0.10”) and press
Enter
.
3. Enter the user name (default: admin) and password (default: admin) in the login page and click
Conrm
.
Network Settings:
Click on
Network->Basic->IPv4 Cong
You can configure the network in the following ways:
DHCP:
By default, the phone attempts to contact a DHCP server in your network to obtain its valid
network settings, e.g., IP address, subnet mask, gateway address and DNS address.
Static IP Address:
If the phone cannot contact a DHCP server for any reason, you need to configure
the IP address, subnet mask, gateway address, primary DNS address and
secondary DNS address for the phone manually.
PPPoE:
If you are using an xDSL modem, you can connect your phone to the Internet via PPPoE
mode. Contact the ITSP for the user name and password.
Note:
The wrong network settings may result in the inaccessibility of the phone and may have an impact on the
network performance. Contact your system administrator for more information.
Account Settings:
Click on
Account->Register
Parameters of the account:
Register Status: It shows the register status of the current account.
Line Active: You can select Enabled/Disabled to enable/disable the account.
Label: It is shown on the LCD to identify the account.
Display Name: It is shown as caller ID when placing a call.
User Name: It is provided by ITSP for registration (required).
Register Name: It is an authenticated ID for authentication provided by ITSP (required).
Password:
It is provided by ITSP for registration (required).
Server Host:
It is provided by ITSP for registration (required).
Register status icons on the LCD screen:
Registered Register Failed
Registering
Note:
Check with your system administrator if any error appears during the registration process or a specific
configuration is required for your registration.
Conguring via phone user interface
Network Settings:
Press the
Menu
soft key when the phone is idle, select
Settings->Advanced Settings (password:
admin) ->Network->WAN Port/VLAN/Webserver Type/802.1x Settings
to configure the network.
Account Settings:
Press the
Menu
soft key when the phone is idle, select
Settings->Advanced Settings (password:
admin) ->Account
to configure the account.
Note:
For more information on account parameters, refer to
Conguring via web user interface
.

Yealink SIP-T19P Specifications

General

Speakerphone	Yes
Voice codecs	CNG, G.711, G.723, G.726, G.729ab, VAD
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Front camera	No
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Security algorithms	802.1x RADIUS, AES, HTTPS
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3u
Supported network protocols	IPv6
Ethernet LAN (RJ-45) ports	2
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	185 mm
Height	143 mm
