Yealink SIP-T23G User Manual

User Guide for the SIP-T23P/G IP Phone
128
5. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
6. Press the Save soft key to accept the change or the Back soft key to cancel.
Hot desking key is configurable via web user interface at the path DSSKey->Line Key.
To use hot desking:
1. Press the hot desking key when the phone is idle.
The LCD screen prompts the following warning:
2. Press the OK soft key, registration configurations of all accounts on the phone will
be cleared immediately.
The login wizard will be displayed as below:
3. Enter the login information in each field.
4. Press the Save soft key to login or the Cancel soft key to cancel.
Intercom is a useful feature in an office environment to quickly connect with the operator
or the secretary. You can press the intercom key to automatically connect with a
preconfigured target extension for outgoing intercom calls, and the target extension will
automatically answer incoming intercom calls by default.
Note
To configure an intercom key via phone user interface:
1. Press Menu->Features->DSS Keys.
Intercom is not available on all servers. Contact your system administrator for more
information.

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
