Yealink SIP-T23G User Manual

User Guide for the SIP-T23P/G IP Phone
66
You can use two headsets when enabling dual headset. To use this feature, you must
physically connect headsets to the headset jack and handset jack respectively. Once
the phone connects to a call, the headset connected to the headset jack will have
full-duplex capabilities, while the one connected to the handset jack will only be able to
listen.
To enable dual headset via web user interface:
1. Click on Features->General Information.
2. Select Enabled from the pull-down list of Dual-Headset.
3. Click Confirm to accept the change.
Note
There are two types of DSS keys: Line Keys and Programable Keys. The details will be
introduced in the following. The SIP-T23P/G IP phone supports 3 line keys and 11
programable keys. For more information on DSS key icon indicators, refer to Icon
Instructions on page 12.
You can assign predefined functionalities to line keys. You can also define a label for a
line key feature which will appear on the LCD screen. Line keys allow you to quickly
access features such as recall and voice mail. The line key LEDs will indicate the
Dual headset is configurable via web user interface only.

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
