Yealink SIP-T23G User Manual

Advanced Phone Features
131
3. Press the Save soft key to accept the change or the Back soft key to cancel.
These specific parameters are configurable via web user interface at the path
Features->Intercom.
To place an intercom call when the target phone is idle:
1. Press the intercom key when the phone is idle.
The called destination plays a warning tone and automatically answers the call in
the speakerphone mode by default.
2. To end the intercom call, press the intercom key again or the EndCall soft key.
You can use multicast paging to quickly and easily broadcast time sensitive
announcements to users who are listening to a specific multicast group. You can
configure a multicast paging key or the paging list key on the phone, which allows you
to send a Real Time Transport Protocol (RTP) stream to the pre-configured multicast
address(es) without involving SIP signaling. You can configure the phone to receive an
RTP stream from pre-configured multicast listening address(es) without involving SIP
signaling. You can specify up to 10 multicast listening addresses.
To configure a multicast paging key via phone user interface:
1. Press Menu->Features->DSS Keys.
2. Select the desired DSS key.
3. Press or , or the Switch soft key to select Key Event from the Type field.
4. Press or , or the Switch soft key to select Multicast Paging from the Key
Type field.
5. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
6. Enter the multicast IP address and port number (e.g., 224.5.6.20:10008) in the Value
field.

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
