Yealink SIP-T23G User Manual

Advanced Phone Features
139
After logging in, you are ready to receive calls from the ACD system. You can press the
ACD key to show your current ACD user status. You can press the Avail/Unavail soft key
to change your ACD user status. ACD user status synchronizes on both IP phone and
ACD system.
When you set the ACD user status to be available, the ACD key LED illuminates solid
green, and then the server begins distributing calls to your phone. When you set the
ACD user status to be unavailable, the ACD key LED flashes green, and then the server
temporarily stops distributing calls to your phone. To log out of the ACD system, press the
Logout soft key.
Note
You can use SCA feature to share an extension which can be registered on two or more
IP phones at the same time. The shared line is indicated by a different line icon.
In the following figure, the first line is private and the second line is shared:
If two phones share a line, an incoming call to this extension will cause both phones to
ring simultaneously. The incoming call can be answered on either phone but not both.
This feature is very useful in the boss and secretary scenario. For example, the secretary
can share the boss's extension on her phone. When there is an incoming call to the
extension of the boss, both the phones of the boss and the secretary will ring
simultaneously. Either the boss or the secretary can answer the call. Calls on the shared
line can be placed on hold, barged in or retrieved from another shared phone.
It is recommended you configure no more than one ACD key per phone. At any time, at
most one ACD key can be in progress on your phone.

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
