Yealink SIP-T23G User Manual

Customizing Your Phone
63
To delete an entry from the call history list:
1. Press the History soft key.
2. Press or to switch among All Calls, Placed Calls, Received Calls, Missed
Calls and Forwarded Calls.
3. Press or to select the desired entry.
4. Press the Delete soft key.
To delete all entries from the call history list:
1. Press the History soft key.
2. Press or to switch among All Calls, Placed Calls, Received Calls, Missed
Calls and Forwarded Calls.
3. Press the Option soft key, and then select Delete All.
4. Press the OK soft key.
The LCD screen prompts "Delete all the call records?".
5. Press the OK soft key to confirm the deletion or the Cancel soft key to cancel.
You can upload your custom logo which will be shown on the idle screen.
To upload a custom logo via web user interface:
1. Click on Features->General Information.
2. Select Custom logo from the pull-down list of Use Logo.

Yealink SIP-T23G Specifications

General

Backlight	Yes
Voice codecs	G.711a, G.722.2, G.726, G.729ab, iLBC
Volume control	Digital
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Silver
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.56 W
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	209 mm
Height	150 mm
