Yealink SIP-T58W Recovery Guide

Recovery Mode on Yealink IP phones
11
5. Press to verify the current firmware version after upgrading successfully.
Note
For VCS (Video Conferencing System) Series
The section is only applicable to the VCS series including VC400, VC120, and VC110.
The following procedures take the VC400/VC120 for reference.
Procedures
1. Long press the recessed Reset key (Use the tip of a pin to hold the reset key) and press on the
codec to trigger the recovery mode. Do not release the Reset key until the recovery mode wizard
appears on the display device.
Note
2. Enter the desired values in the IP Address, Netmask, IP Gateway and TFTP Server fields
respectively.
The IP phone must be configured in the same subnet as the TFTP server.
3. Press on the remote control to complete the recovery mode.
The video conferencing system will download and upgrade the firmware from the TFTP server. After
upgrading, the video conferencing system will initialize successfully and get ready for use.
4. Press on the VCP40 phone to verify the current firmware version after upgrading successfully.
You need to press (for SIP-T19(P) E2 IP phones), tap ->Status (for SIP VP-T49G IP
phones), tap Settings->Status (for VP59/SIP-T58A IP phones) or tap Menu->Status (for
SIP-T57W IP phones), (for SIP-T3 IP phones) to verify the current firmware version since
there is no key.
For VC110, you need to long press the Reset key and reconnect the power adapter to trigger the
recovery mode.
IP Address:
Netmask:
IP Gateway:
TFTP Server:
10. 2. 11.124
255.255.255. 0
10. 2. 11.254
10. 2. 11.123
…. Update Fail ….
Please reboot
Welcome

Yealink SIP-T58W Specifications

General

Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Wall mountable	Yes
Video call	No
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	256-bit AES, HTTPS, TLS, WPA2, WPA3
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	IPv4/IPv6, SIP v1 (RFC2543), v2 (RFC3261), UDP/TCP/DNS-SRV (RFC 3263)
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	2
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
Keypad number of keys	27
Number of function keys	7
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Number of handles included	1 pc(s)
Voice codecs	G.711a, G.722, G.723.1, G.726, G.729, G.729A, G.729B, iLBC

Weight and Dimensions

Depth	220 mm
Width	259.4 mm
Height	215 mm
Weight	8858 g
Package depth	293 mm
Package width	324 mm
Package height	128 mm
Package weight	9556 g
