Yealink UVC40 User Manual

1
AAA Battery×2UVC 40
VCR20
Remote Control
Cable Tie×5
Quick Start Guide
We recommend that you use the accessories provided or approved by Yealink. The use of
unapproved third-party accessories may result in reduced performance.
Use the Yealink original power adapter (48V/0.7A) to charge the endpoint only. The use of the
third-party power adapter may cause the damage to the endpoint.
The USB cable in the MVC400/ZVC400 package is 2.5 meters long.
Mounting Bracket
and Accessories
Power Adapter
×4
×2
×2
Silicone Pad×2
Put on a Flat Surface
Package Contents
7m
USB Cable
TV TV
UVC40 Installation

Yealink UVC40 Specifications

General

Megapixel	20 MP
Camera type	Single camera
Sensor type	CMOS
Image sensor size	- \
Optical sensor size	1/1 \
Field of view (FOV) angle	133 °
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina
Windows operating systems supported	Windows 10, Windows 7
Built-in microphone	Yes
HD type	-
Maximum frame rate	60 fps
Maximum video resolution	- pixels
Product color	Black
USB cable length	7 m
Product type	Personal video conferencing system
Certification	CE
Number of cameras	1
Number of persons	- person(s)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
DC output current	0.7 A
DC output voltage	48 V
Power source type	DC
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Number of microphones	8
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	68 mm
Width	600 mm
Height	82 mm
Weight	2560 g
