PARTS LIST
KEY NO. PART NO. Q'TY(PCS) DESCRIPTION
1 5510-01 1 MAIN FRAME
2 5510-02 2 SIDE FRAME END CAP
3 5510-03 1 RUNNING MAT
4 5510-04 6 SINGLE SIDE FOAM TAPE (L=50mm)
5 5510-05 3 SINGLE SIDE FOAM TAPE (L=80mm)
6 5510-06 2 RUNNING BOARD SUPPORT
7 5510-07 1 FRONT RUNNING BOARD SUPPORT
8 5510-08 2 SINGLE SIDE FOAM TAPE (L=1050mm)
9 5510-09 2 SINGLE SIDE FOAM TAPE (L=20mm)
10 5510-10 1 FRAME BOARD
11 5510-11 8 20mm X 12mm CAP WASHER
12 5510-12 8 5.3mm X 18mm FLAT WASHER
13 5510-13 8 3/16" X 1 1/4" SELF TAPPING SCREW
14 5510-14 1 REAR STABILIZER ASSEMBLY
15 5510-15 2 REAR STABILIZER CA
16 5510-16 2 19.6mm X 10mm METAL BUSH
17 5510-17 2 10.5mm X 38mm FLAT WASHER
18 5510-18 2 M10 LOCKNUT
19 5510-19 2 10mm X 25mm CARRIAGE BOLT
20 5510-20 2 PULL RELEASE PIN
21 5510-21 1 FRONT ROLLER
22 5510-22 1 MAGNET
23 5510-23 2 3mm X 6mm MACHINE SCREW
24 5510-24 1 FRONT PIVOT SHAFT
25 5510-25 4 16.7mm ROLLER WASHER
26 5510-26 4 ROLLER SPACER
27 5510-27 1 DRIVING T-BELT
28 5510-28 1 5/16" X 3" ADJUSTMENT BOLT
29 5510-29 4 8.2mm X 16mm WASHER
30 5510-30 1 5/16" LOCKNUT
31 5510-31 1 REAR ROLLER
32 5510-32 1 REAR PIVOT SHAFT
34 5510-34 2 5/16" X 2 1/2" ADJUSTMENT BOLT
35 5510-35 1 MOTOR PULLEY
36 5510-36 2 6mm X 12mm FIXING SCREW
37 5510-37 1 FLYWHEEL
38 5510-38 1 5mm X 30mm FIXING PIN
39 5510-39 2 6mm X 10mm FIXING SCREW
40 5510-40 1 15mm C-SPRING CLIP
41 5510-41 1 MOTOR
42 5510-42 1 MOTOR SUPPORT FRAME
43 5510-43 1 RUBBER STOPPER
44 5510-44 1 41mm X 40mm END CAP
45 5510-45 1 RUBBER END CAP WASHER
46 5510-46 2 25mm X26mm RUBBER BUSHING
47 5510-47 1 PIVOT ROD
48 5510-48 2 5/16" SPRING WASHER
49 5510-49 2 8mm X 20mm HEX HEAD BOLT
